Saber AT

Features and Scenarios

  • Advanced Autotracking

    The Saber AT comes with advanced autotracking capabilities onboard. Using state of the art algorithmic processing to analyze shape and motion, our smart technology creates a seamless autotracking experience.

  • 20x Optical Zoom

    20x Optical Zoom gets you up close and personal. Even in the largest event spaces, the Saber AT's zoom features will give you the power to see everything with smooth motion, accuracy, and precision.

  • 1080p @ 60fps

    The Saber AT runs video at up to 1080p Full HD at 60 frames per second. This smooth, high resolution video can run through the USB, HDMI, SDI, and LAN connections simultaneously, giving your livestreaming or recorded video excellent definition, superb image quality, and much needed flexibility.

  • Connectivity

    The Saber AT gives you options. Run Full HD Video out through the HDMI, 3G-SDI, IP, and USB-C (USB2.0) ports, enjoy Line in Audio through the 3.5mm jack, and open up a world of integration options with PoE+.

Saber AT
  • Sensor
  • 1/2.8 inch 2.4MP CMOS Sensor
  • Video Format
  • HDMI: 1920*1080P60/50/30/25/59.94/29.97/24/23.98; 1920*1080160/50/59.94; 1280*720P60/50/30/25/59.94/29.97

    IP: Main Stream: 1920*1080@15~60;1280*720@15~60;1024*576@15~60 Sub Stream: 640*360@15~30

    3G-SDI: 1920*1080P60/50/30/25/59.94/29.97/24/23.98; 1920*1080160/50/59.94; 1280*720P60/50/30/25/59.94/29.97

    USB Type-C: NV12 :1920*1080p5;1280*720pl5;1024*576P25;800*448P30; YUY2:1920*1080p5;1280*720pl0;1024*576P15;800*448P30; MJPG:1920*1080P30; 1280*720P30; 1024*576P30; 800*448P30 H.264/HEVC: 1920*1080P30; 1280*720P30; 1024*576P30; 800*448P30
  • Zoom
  • 20x Optical
  • Horizontal View Angle
  • 60°(Wide) ~3.2°(Tele)
  • Preset
  • Remote controller: 10; Serial port: 128; Accuracy:0.1°
  • Pan Rotation Angle
  • -170° ~+170°
  • Tilt Rotation Angle
  • -30° ~+90°
  • Pan Rotation Speed
  • 0.1°~120°/s
  • Tilt Rotation Speed
  • 0.1°~80°/s
  • Control Port
  • RS232(RS485), IP
  • Video Port
  • LAN, HDMI, 3G-SDI, USB Type-C
  • Audio Port
  • 3.5mm Line In
  • Network Port Speed
  • 1000M
  • Noise Reduction
  • 2D & 3D
  • Minimum lux
  • 0.01 lux
  • White Balance
  • Auto/Manual/Auto tracking/Push/Indoor/Outdoor/Color Temperature
  • Exposure
  • Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
  • Anti-Flicker
  • OFF, 50Hz, 60Hz
  • Image Flip
  • Supported
  • Mirroring
  • Supported
  • Focus
  • Auto/Manual
  • Iris
  • Auto/Manual
  • Electronic Shutter
  • Auto/Manual
  • Gamma
  • Supported
  • Backlight Compensation
  • Supported
  • Tilt Rotation Angle
  • -30° ~+90°
  • Pan Rotation Speed
  • 0.1°~120°/s
  • Tilt Rotation Speed
  • 0.1°~80°/s
  • Control Port
  • RS232(RS485), IP (Including NDI®|HX3 Variant)
  • Video Port
  • LAN, HDMI, 3G-SDI, USB Type-C
  • Audio Port
  • 3.5mm Line In
  • Network Port Speed
  • 1000M
  • Noise Reduction
  • 2D & 3D
  • Minimum lux
  • 0.01 lux
  • White Balance
  • Auto/Manual/Auto tracking/Push/Indoor/Outdoor/Color Temperature
  • Exposure
  • Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
  • Anti-Flicker
  • OFF, 50Hz, 60Hz
  • Image Flip
  • Supported
  • Mirroring
  • Supported
  • Focus
  • Auto/Manual
  • Iris
  • Auto/Manual
  • Electronic Shutter
  • Auto/Manual
  • Gamma
  • Supported
  • Backlight Compensation
  • Supported
